Herb Extract Machine
Product Application of herbal extraction and concentration equipments unit:
The herbal extraction and concentration equipments unit on sale is suitable for flowers and plants oils (volatile oil),adopts steam distillation apparatus to Waterproof distillation. The steam distiller grapefruit essential oil extractor can extract plant volatile oil effectively. The collection of various types of plant volatile aroma more significant, This steam distiller grapefruit essential oil extractor is suitable for companies set up factories near the plant of origin. Equipment by steam distillation extraction method, placing the aromatic plants in a distillation vessel,then put the high temperature of the steam into it(or put the spices and water together to boil),in this case the essential oil containing aroma components plants will diffuse into the water vapor to form an oil and water azeotrope;azeotrope cooled thereafter, since the oil does not dissolve in water through a water separator to separate the oil, and thus it water Separation and the formation of oil we need. Equipment can be confining water by distillation or co-distillation, this device is a new, multi-functional, multi-purpose plant oil extraction unit can efficiently collect the volatile active ingredient plant oils, aromatic plants dew, plant extracts and so on.
Main Features:
1) 2 in 1 compact design, extraction, concentration/solvent recovery in one machine .
2) Equip with centrifuge pump and vacuum pump, just connect the steam, cooling water and power supply to boot the machine.
3) Equip with Oil-water separator, can collect the volatile oil in the herbs during extraction.
4) Material contact parts adopt SS304/SS316 with fine polishing to the liner, meet GMP requirement.
Hempseed oil
The appearance and characteristics are very close to the low iodine value of linseed oil, but slightly greenish.
The approximate fatty acid composition is: 10.1% saturated acid, 16% oleic acid, 46% linoleic acid, and 28% linolenic acid.
The acid value is 3 mg KOH/g, the iodine value is 149-167, and the relative density is 0.925-0.933 (15/15 ° C). The freezing point is about 16 °C.
The main ingredients are glycerides of linoleic acid, linolenic acid and oleic acid.
Used in industries such as paints and soaps.
Machine Main Technical Data:
| Model | LTN- 0.1/25 | LTN -0.2/50 | LTN- 0.3/75 | LTN- 0.5/125 | LTN- 1/250 | LTN- 2/500 | LTN-3/750 | LTN-4/1000 | LTN5/1250 | LTN6/ 1500 |
| The volume of extracting (m³) | 0.1 | 0.2 | 0.3 | 0.5 | 1 | 2 | 3 | 4 | 5 | 6 |
| Raw Material Input Capacity (kg) | 10-15 | 20-30 | 30-45 | 50-70 | 100-150 | 200-300 | 300-450 | 400-600 | 500-700 | 600-800 |
| Capacity of Concentrating Evaporator | 25 kg/ hour | 50 kg/ hour | 75 kg/ hour | 125 kg/ hour | 250kg/ hour | 500kg /hour | 750kg/ hour | 1000 kg/ hour | 1250 kg/ hour | 1500 kg/ hour |
| Water Circulation Capacity | 10-15T | 10-15T | 10-15T | 10-15T | 15-20T | 15-20T | 15-25T | 15-25T | 20-30T | 20-30T |
| The time of extraction (h) | 6-8 | 6-8 | 6-8 | 6-8 | 8 | 8 | 8 | 8 | 8 | 8 |
| Concentrate density (%) | 1.2-1.35 |
| The work temperature of extracting and concentrating (°C) | Water: 50-90°C Alcohol: 40-80°C |
| Power of Vacuum Pump | 3kw | 4KW | 4.5KW | 5KW | 6.5kw | 8KW | 9kw | 10kw | 11kw | 12kw |
